Smarten Saver Series 5.5 kVA (5500VA) 96V Pure Sine Wave Heavy-Duty Commercial Solar PCU with PWM Controller, Under 10ms UPS Transfer & 90V Low-Voltage Smart Charging | SAVER 5500 (96V)
Up to Rs 750.00 OFF
Up to Rs 7,000.00 OFF
Up to Rs 16,000.00 OFF
Rs 20,000.00 OFF
| Specification Attribute | Technical Detail |
| Brand | Smarten |
| Series / Range | Saver Solar PCU Series |
| Model / Item Designation | SAVER 5500 / 96V |
| Product Type | Heavy-Duty Pure Sine Wave Commercial Solar PCU (HKVA) |
| Generic / Common Name | 5.5 kVA Solar Inverter / 96V Solar PCU / Commercial Solar Backup Station |
| Capacity / Rating | 5500 VA (5.5 kVA) |
| System DC Operating Voltage | 96 V DC (Requires 8 x 12V Batteries in Series) |
| Inverter Technology | Advanced DSP (Digital Signal Processing) Control Technology |
| Output Waveform | Pure Sine Wave (Noiseless, Motor & Sensitive Equipment Safe) |
| Output Voltage & Frequency | 220V AC | 50 Hz |
| Overall System Efficiency | 88% System Efficiency (Up to 30% Power Savings) |
| Solar Charge Controller | Built-in Advanced PWM (Pulse Width Modulation) |
| Solar Priority & Sharing | 100% Solar Priority with Smart Solar & Grid Load Sharing |
| Solar Panel Compatibility | Wide Input PV Range (Compatible with All Types of Solar Panels) |
| Low-Voltage Charging Capability | Active Smart Charging Down to 90V Mains Input Voltage |
| Deep Discharge Recovery | Inbuilt Independent Battery Charger (Revives Deep Discharged Batteries) |
| Mains Bypass Feature | Allows Direct Mains Supply Bypass Without Connecting Batteries |
| Changeover Transfer Time | Less than 10 milliseconds (< 10 ms Computer-Safe UPS Mode) |
| Operational Modes | Smart UPS Mode (for IT/PC loads) & WUPS Mode (Wide Window) |
| Battery Compatibility | Flooded Lead Acid (LA), Tall Tubular & Sealed Maintenance Free (SMF) |
| Circuit Protections | Short-Circuit, Overload, Wiring Fault, High Input Voltage, Reverse Connections, Over-Temperature, Reverse PV & High PV Protection |
| User Interface / Display | Graphical LCD Display for Live Status Monitoring |
| Target Power Systems | Commercial Petrol Pumps, Dental Clinics, Healthcare Facilities & Large Residences Across Nepal |
| Best Used For | Air Conditioners, Water Geysers, Heavy Photocopiers, Dental Chairs & Whole-Facility Solar Power |
-
Advanced DSP Pure Sine Wave Technology: Combines high-speed DSP processing with clean 220V AC pure sine wave power to run heavy mixed loads—such as air conditioners, water geysers, commercial photocopiers, and dental chairs—without motor hum or thermal wear.
-
100% Solar Priority & Smart Sharing: Inbuilt advanced PWM solar charge controller automatically manages smart load sharing between solar arrays and utility grid power, delivering up to 30% power savings and 88% overall system efficiency.
-
High-Efficiency 96V DC High-Voltage Bus: Operates on an eight-battery series string (8 x 12V), reducing operating current, minimizing transmission line heat losses, and maximizing inverter conversion performance during extended backup cycles.
-
Computer-Safe Transfer & Battery-Free Mains Bypass: Delivers an ultra-fast changeover transfer time under 10 milliseconds in UPS mode to protect desktop computers and servers, and allows direct mains bypass operation without connecting batteries.
-
Zero-Volt Battery Recovery & 90V Smart Charging: Features an independent internal recovery charger to rescue deeply discharged batteries from zero volts, with active smart charging operating down to 90V mains input across a wide AC voltage window.
