| Feature | Details |
| Brand | Uniview (UNV) |
| Model Number | NSW2020-8T2GT-POE-IN |
| Product Type | Unmanaged 8-Port PoE Switch with 2 Gigabit Uplink Ports |
| Port Configuration | 8 × 10/100Mbps RJ45 PoE Ports + 2 × 10/100/1000Mbps RJ45 Uplink Ports |
| PoE Standards | IEEE 802.3af, IEEE 802.3at |
| PoE Power Delivery | Max 120W Total Budget / Up to 30W Max per Single Port |
| PoE Pin Assignment | Mode A (1, 2, 3, 6) & Mode B (4, 5, 7, 8) |
| Switching Fabric Capacity | 5.6 Gbps |
| Forwarding Performance | 4.17 Mpps |
| Packet Buffer & MAC Table | 2 Mbit / 4K MAC Entries |
| Network Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3x, IEEE 802.3az, IEEE 802.3af, IEEE 802.3at |
| Priority Ports | Ports 1 to 2 (Hardware VIP Priority) |
| Working Modes | Default (Normal Mode) / Extend Mode (Surveillance Mode up to 250m with Port Isolation) |
| Cooling System | Fanless / Natural Convection Silent Cooling (0 Fans) |
| LED Indicators | Power (Normal/Abnormal/Over-85% Load Alert), LINK/ACT Activity Indicators |
| Power Supply & Max Draw | AC 100–240V, 50/60Hz / Max 130W |
| Chassis Dimensions (W × D × H) | 169 mm × 132 mm × 40 mm |
| Product Weight | 0.84 kg |
| Enclosure & Regulatory | Industrial Sheet Metal / NDAA Compliant |
| Operating Environment | 0°C to 45°C (32°F to 113°F) / 10% to 90% RH (Non-condensing) |
| Best Used For | IP CCTV Camera Networks, Wireless AP Deployments, VoIP Systems & Office Networks |
-
8 PoE Downlink + 2 Gigabit Uplink Architecture: Features 8× 10/100Mbps 802.3af/at PoE ports combined with 2× high-speed 10/100/1000Mbps Gigabit uplinks to prevent video bottlenecks when routing feeds to NVRs or core networks.
-
Robust 120W Power Budget (30W Single Port): Supports up to 30W on individual ports and 120W overall capacity, powering power-hungry PTZ units, night illuminators, and IP cameras across Nepal.
-
Extended 250m Transmission Mode: One-touch surveillance mode extends data and power transmission over copper lines up to 250 meters while isolating downlink ports to suppress network storms.
-
Hardware VIP Priority on Ports 1–2: Allocates critical bandwidth and power priority to Ports 1 and 2, guaranteeing uninterrupted live view transmission for mission-critical surveillance zones under heavy traffic.
-
Fanless Silent Metal Design & NDAA Compliant: Enclosed in a compact, rugged metal chassis that dissipates heat without noisy cooling fans, supported by intelligent 85% power threshold LED alerts and full NDAA compliance.
