| Specification Category | Hikvision DS-2SE2C400MWG-E/12 Camera Details |
| Model Number | DS-2SE2C400MWG-E/12 |
| Gross Capacity | Dual Channel Layout: [Bullet/Panoramic Channel] & [PTZ/Tracking Channel] |
| Cooling Type (Video Codec) | Main Stream Profile Compression: H.265 / H.264 / Smart264 / Smart265 |
| Compressor (Resolution) | Dual 2560 × 1440 Quad HD Real-Time Smooth Frame Video Processing Engine |
| Energy Rating (Power Supply) | PoE: IEEE 802.3at Class 4 Max 21.5W / 12 VDC ± 25% Max 18W Coaxial Grid |
| Net Dimensions | 134 mm × 213.5 mm × 291.7 mm (5.3" × 8.4" × 11.5") Shell Profile |
| Shelving (Focal Length) | [Panoramic Channel]: 2.8 mm Fixed Lens | [PTZ Channel]: 8 mm Motorized Lens |
| Body Material | Heavy-Duty Impact-Resistant Technical Polycarbonate (PC) Casing Structure |
| Glass Type (Optical FOV) | [Panoramic]: 114° Diagonal (94° Horiz) | [PTZ]: 51° Diagonal (44° Horiz) Arcs |
| Security (Local Storage) | On-Board Memory Card Slot Supporting MicroSD/SDHC/SDXC Up to 512 GB |
| Portability (Movement Range) | Pan Range: 0° to 355° (Panoramic) / 0° to 345° (PTZ) | PTZ Tilt Range: 0° to 80° |
| Lighting (Hybrid Supplement) | Dual IR & Warm White Supplementary Illumination Ranges Reaching Up to 30 m |
| Gas Type (Audio Modules) | Built-In Microphone & High-Output Speaker with Environment Noise Filtering |
| Protection Certification | IP66 Weather-Proof Standard, Surge Protection & Voltage Transient Protection |
TandemVu Panoramic & Tracking Dual Sync: Operates a 2.8 mm panoramic bullet overview channel alongside an 8 mm motorized pan-tilt tracking channel simultaneously to secure massive spaces without losing fine focal metrics.
1440p Quad HD Dual Sensor Nodes: Outfitted with independent 1/2.8" Progressive Scan CMOS processing modules capturing dual 2560 x 1440 resolution streams for rapid boundary protection.
Smart Hybrid Dual-Light Automation: Features integrated long-range IR and White Light supplement arrays up to 30 meters, dynamically switching from stealth tracking to color light deterrence upon detection.
Deep Learning Human & Vehicle Filters: Programmed with smart edge analytics configured to classify humans and vehicles accurately, dropping environmental false alarms caused by rain or foliage to zero.
Two-Way Audio Terminal & 512 GB Storage: Built-in high-sensitivity microphone and speaker support real-time audio tracking alerts, paired with an internal card slot supporting up to 512 GB microSD storage.
