| Specification Category | Hikvision DS-2CD1083G2-LIU(F) Camera Details |
| Model Number | DS-2CD1083G2-LIU / DS-2CD1083G2-LIUF |
| Gross Capacity | 1/2.7" Progressive Scan CMOS 8 MP Image Node |
| Cooling Type (Video Codec) | Main Stream: H.265+/H.265/H.264+/H.264 |
| Compressor (Resolution) | 3840 × 2160 Ultra HD 4K Recording Engine |
| Energy Rating (Power Core) | 12 VDC Max 5W / PoE IEEE 802.3af Max 6.5W Grid |
| Net Dimensions | 170.8 mm × 66 mm × 69.1 mm (6.7" × 2.6" × 2.7") |
| Shelving (Focal Lens) | 2.8 mm (134° Diag FOV) / 4 mm (108° Diag FOV) Optional |
| Body Material | Heavy-Duty Metal & Engineering Plastic Composite Frame |
| Glass Type (Night Vision) | Smart IR & White Light Supplementary Range Up to 30 m |
| Security (Local Storage) | Built-In MicroSD Slot Up to 512 GB (Supported on -F Model Only) |
| Portability (Audio Logic) | Built-In Microphone with Environmental Noise Filtering (Mono Sound) |
| Lighting (Image Enhance) | 120 dB True WDR, BLC, HLC, 3D DNR, 4 Polygon Privacy Masks |
| Gas Type (Network Protocol) | TCP/IP, DHCP, DNS, Hik-Connect Client, ONVIF API |
| Protection Certification | IP67 Water and Dust Resistant Rated (IEC 60529-2013) |
Smart Hybrid Dual-Light System: Features an advanced supplement light grid that automatically shifts up to 30 m from stealth infrared mode to full-color White Light when a target is detected.
Ultra HD 4K Resolution Matrix: Outfitted with a premium 8 Megapixel Progressive Scan CMOS sensor delivering razor-sharp 3840 x 2160 video streams for high-fidelity asset auditing.
Deep Learning Intelligent Detection: Built-in smart network edge analytics actively isolate human and vehicle movement paths, filtering out false alerts caused by wind, lights, or flying debris.
Real-Time Audio Security & Filtering: Integrated high-sensitivity microphone features environmental noise filtering to capture clear mono sound paths alongside video streams.
Industrial Weatherproof IP67 Protection: Engineered with a robust metal and plastic composite body certified to IEC 60529 standards, maintaining complete liquid and dust isolation from -30 °C to 60 °C.
