| Feature | S1600V2-6P | S1600V2-10P | S1600V2-18P | S1600V2-26P | S1600V2-26S |
| Brand | H3C | H3C | H3C | H3C | H3C |
| Model Number | S1600V2-6P | S1600V2-10P | S1600V2-18P | S1600V2-26P | S1600V2-26S |
| Product Type | Web Managed Gigabit Access Switch | Web Managed Gigabit Access Switch | Web Managed Gigabit Access Switch | Web Managed Gigabit Access Switch | Web Managed Gigabit Access Switch |
| Fixed Ports | 5 x GE + 1 x SFP | 9 x GE + 1 x SFP | 16 x GE + 2 x SFP | 24 x GE + 2 x SFP | 24 x GE + 2 x 10G SFP+ |
| Switching Capacity | 12 Gbps | 20 Gbps | 36 Gbps | 52 Gbps | 88 Gbps |
| Forwarding Rate | 8.93 Mpps | 14.88 Mpps | 26.784 Mpps | 38.688 Mpps | 65.482 Mpps |
| MAC Address Table | 2K Entries | 4K Entries | 8K Entries | 8K Entries | 16K Entries |
| Static MAC / VLANs | 32 Static MAC / 16 VLANs | 32 Static MAC / 16 VLANs | 32 Static MAC / 16 VLANs | 32 Static MAC / 16 VLANs | 32 Static MAC / 16 VLANs |
| Port Surge Protection | 6kV | 6kV | 6kV | 6kV | 6kV |
| Cooling Architecture | Fanless Natural Cooling | Fanless Natural Cooling | Fanless Natural Cooling | Fanless Natural Cooling | Fanless Natural Cooling |
| Power Consumption | Min 2W / Max 4W | Min 3W / Max 6W | Min 3.5W / Max 11.2W | Min 4.3W / Max 16W | Min 8W / Max 22W |
| Input Power Supply | AC 100V ~ 240V, 50/60Hz | AC 100V ~ 240V, 50/60Hz | AC 100V ~ 240V, 50/60Hz | AC 100V ~ 240V, 50/60Hz | AC 100V ~ 240V, 50/60Hz |
| Dimensions (W×D×H) | 130 × 124 × 27 mm | 185 × 125 × 27 mm | 440 × 160 × 44 mm | 440 × 160 × 44 mm | 440 × 160 × 44 mm |
| Weight | ≤ 0.6 kg | ≤ 0.6 kg | ≤ 2.1 kg | ≤ 2.2 kg | ≤ 2.5 kg |
| MTBF (Years) / MTTR | 114.00 Yrs / 1 Hr | 100.76 Yrs / 1 Hr | 84.36 Yrs / 1 Hr | 84.36 Yrs / 1 Hr | 116.23 Yrs / 1 Hr |
| Operating Temp | -5°C to 50°C | -5°C to 50°C | -5°C to 50°C | -5°C to 50°C | -5°C to 50°C |
| Operating Humidity | 5% to 95% RH (Non-condensing) | 5% to 95% RH (Non-condensing) | 5% to 95% RH (Non-condensing) | 5% to 95% RH (Non-condensing) | 5% to 95% RH (Non-condensing) |
| Management Features | Web GUI, Loopback Detection, DHCP Snooping, Port Mirroring, Storm Suppression, 8 QoS Queues | Web GUI, Loopback Detection, DHCP Snooping, Port Mirroring, Storm Suppression, 8 QoS Queues | Web GUI, Loopback Detection, DHCP Snooping, Port Mirroring, Storm Suppression, 8 QoS Queues | Web GUI, Loopback Detection, DHCP Snooping, Port Mirroring, Storm Suppression, 8 QoS Queues | Web GUI, Loopback Detection, DHCP Snooping, Port Mirroring, Storm Suppression, 8 QoS Queues |
| Certifications | CE, RoHS, FCC, UL 62368-1 | CE, RoHS, FCC, UL 62368-1 | CE, RoHS, FCC, UL 62368-1 | CE, RoHS, FCC, UL 62368-1 | CE, RoHS, FCC, UL 62368-1 |
| Best Used For | Small Office Desktop Aggregation | Branch Office Distribution | Medium Commercial Rack Wiring | Large Enterprise Access Layers | 10G Uplink Aggregation & Core Links |
-
Comprehensive Port Scalability with SFP/SFP+ Uplinks: Offers configurations ranging from 6-port desktop models up to 26-port rackmount units with 1G SFP or 10G SFP+ optical uplinks, delivering up to 88 Gbps switching capacity and 65.482 Mpps forwarding.
-
Intuitive Web-Based Layer-2 Management: Supports simplified browser management with essential enterprise features, including port-based VLANs, 8 QoS queues, port mirroring, loopback detection, and 10,000-byte jumbo frames.
-
Carrier-Grade 6kV Surge Protection: Integrated 6kV surge suppression across all Ethernet ports safeguards connected devices and network infrastructure from electrical transients and outdoor lightning induction.
-
Fanless Silent Natural Heat Dissipation: 100% fanless architecture across all models ensures completely silent operation, zero dust buildup, lower energy consumption (down to 2W idle), and MTBF ratings reaching 116 years.
-
Enterprise Hardware Security & Durability: Features robust steel enclosures, wide-range internal AC power supplies (100V–240V), DHCP snooping, and storm suppression to prevent broadcast loops and network intrusion across installations in Nepal.
